Cool Vector Flower


Step 1. Create a New Document with 500px x 500px Artboard Setup. Select RGB color for Color Mode.

Step 2. Select the Polygon Tool. Click once at the artboard and enter Radius: 70, Sides: 10.

Just fill it with black color first with no stroke.

Cool Vector Flower image 1

Cool Vector Flower image 2

Step 3. Go to Effect > Distort and Transform > Pucker and Bloat. Enter 50 and OK.

Cool Vector Flower image 3

Step 4. Go to Effect > Distort and Transform >Roughen. Enter Size: 10, Relative, Detail: 0 and Points: Smooth. Press OK. You'll get something like this:

Cool Vector Flower image 4

Step 5. Apply a green Radial Gradient (F9) on it as below:

Cool Vector Flower image 5

Click the left slider and set Location: 50. It's done for the first layer of our petals.

Step 6. Click on Polygon Tool once again. Enter Radius: 50, Sides: 15. Go to Effect > Distort and Transform > Pucker and Bloat. Enter 100 and OK.

You'll get something like below:

Cool Vector Flower image 6

The Gradient effect will be automatically applied on it. Change the left slider Location: 30.

Then go to Effect > Distort and Transform > Tweak. Enter Horizontal: 10, Vertical: 10, Relative, Anchor Points: Unchecked, "In" Control Points: Checked and "Out" Control Points: Checked. Click Preview to know how its look and click OK.

Cool Vector Flower image 7

Cool Vector Flower image 8

Place our second petals in front of the first one:

Cool Vector Flower image 9

Step 7. Repeat Step 6 to create the next petals. Enter these values.

Polygon Tool, Radius: 30, Sides: 15.

Pucker and Bloat: 100 and

Tweak, Horizontal: 20, Vertical: 20, Relative, Anchor Points: Unchecked, "In" Control Points: Checked and "Out" Control Points: Checked. Click OK.

Set the Gradient left slider Location: 15.

Cool Vector Flower image 10

And place it in front of our second petals.

Cool Vector Flower image 11

Step 8. Ok, the last one. Select the Ellipse Tool or just press L. Click once on the artboard and enter Width: 40px, Height: 40px and click OK.

Cool Vector Flower image 12

Then go to Effect > Distort and Transform > Zig Zag. Enter Size: 15, Absolute, Ridges per segment: 20 and Points: Smooth.

Cool Vector Flower image 13

After that, go to Effect > Distort and Transform > Roughen. Enter Size: 5, Relative, Detail: 5 and Points: Corner.

Set its Gradient left slider Location: 20.

Cool Vector Flower image 14

And place it in front of our third petals. Select all petals, go Object > Group.

Cool Vector Flower image 15

Done for the flower.

Step 9. Select the Rounded Rectangle Tool. Click once on the artboard and enter Width: 300px, Height: 250px and Radius: 20.

Fill it with white color with no stroke.

Go to Effect > Stylize > Drop Shadow. Enter X Offset: 1px, Y Offset: 1px, leave everything as default as click OK.

Cool Vector Flower image 16

Step 10. Right click the Rounded Rectangle > Arrange > Send to Back or just press Ctrl+Shift+[.

Place our flower to the bottom-left of the rectangle. Make the duplicate of our flower. Resize to make it bigger. Press Shift key while resizing it. Then, set Transparency (Shift+F10): Multiply and Opacity: 30.

Make another three or five duplicates and resize it to make it smaller. Place it on the top-right and bottom-right or anywhere that suits you.

Our final result:

Cool Vector Flower Tutorial: Final Result

The flower with some other color settings:

Cool Vector Flower image 18

I hope you guys enjoy this tutorial and that's all for today. Yeahh!!!
